| PARAMETER | VALUE |
|---|---|
| Max head | 28 m |
| Maximum efficiency | 100 m³/h |
| Self-priming time | 80s / 4m |
| Inlet diameter | 100 mm / 4" |
| Outlet diameter | 100 mm / 4" |
| Max suction head | 7 m |
| Net weight | 68 kg |
| Oveall dimensions | 630×480×600 mm |
| PARAMETER | VALUE |
|---|---|
| Max head | 28 m |
| Maximum efficiency | 100 m³/h |
| Self-priming time | 80s / 4m |
| Inlet diameter | 100 mm / 4" |
| Outlet diameter | 100 mm / 4" |
| Max suction head | 7 m |
| Net weight | 68 kg |
| Oveall dimensions | 630×480×600 mm |
| PARAMETER | VALUE |
|---|---|
| Engine displacement | 420 cm³ |
| Max power | 9.9 kW / 13.46 Hp |
| Max torque | 26.5 Nm / 2500 rpm |
| Starting system | Recoil |
| Engine type | 4-stroke, OHV, gasoline engine |
| Number and arrangement of cylinders | Single-cylinder |
| Rated power | 9.0 kW / 12.2 Hp |
| Cooling system | Air-cooled |
| Fuel consumption | ≤4.49 l/h |
| Oil system capacity | 1.1 l |
| Net weight | 31 kg |
